Measuring Relative Humidity: 15 Do’s and Don’ts

Principle n°1 Make sure your sensor measures exactly what you want to measure

The characteristics of the air in a space are generally not uniform. Take temperature, for example. Air near cold surfaces (walls, windows, metal surfaces, etc.) is not the same temperature as freely flowing air. Similarly, the relative humidity measured at certain locations in a space can differ greatly depending on where the measurement is taken, in part because the temperature has an influence on it.

1. Ensure that the airflow around your sensor is appropriate for your application.
2. Stay away from surfaces (walls, windows, cold surfaces, etc.) unless that is the purpose of your application.
3. After positioning your device, wait for a few minutes (ideally 30 minutes) before starting to measure, to prevent its own presence from affecting the air it measures.
4. Avoid sources of radiant heat (e.g. intense light, a motor that gets hot,...)
5. Make sure that the sensor is in the open air. Avoid sensors positioned in a closed housing.

Principle n°2 Keep an eye on the dew point

It is important to keep an eye on the dew point because it is the "gatekeeper" of condensation. If you have a Dracal device that measures temperature and relative humidity, you automatically have access to a virtual channel that calculates the dew point for you: take advantage of this critical information.

6. Prevent condensation from forming on your sensor, by making sure the air you are measuring is above the dew point.
7. Position your sensor so that it faces downward, especially in a high relative humidity environment. This way, in the event of condensation, droplets formed on the sensor will not remain on the sensor or wire, allowing you to dry it out and perhaps restore its function.

Principle n°3 Your sensors are designed to measure air that is similar in composition to fresh air.

Air is primarily composed of gases, but may also contain small particles called aerosols. Some of these aerosols can directly attack the materials that make up your sensor itself and permanently damage it.

8. Avoid vapors containing corrosive agents, such as salt water vapors, which can cause permanent rupture.
9. Avoid vapors containing very basic or very acidic agents, as they affect the conductivity of the water and can cause short circuits in the sensor electronics.
10. If you have not already done so, protect your unit from dust and other contaminants.

Principle n°4 Remember that you are dealing with a sensitive electronic device

The accuracy of the measurements returned by your device is the result of the electronics being sensitive to its environment. The more your device is treated as a "sensitive" (not necessarily fragile) entity, the better the quality of the measured data.

11. When positioning your device, give it time (30 minutes, ideally) to stabilize before starting to perform measurements. This recommendation is crucial when calibrating the unit.
12. Place your unit and any attached wires in a vibration-free location. Mechanical stress on your unit's electronics could introduce noise into your readings.
13. Place your unit away from extreme magnetic fields.
14. Always use your unit within the recommended operating ranges.
15. Do not ignore the effect of the environment on the physiology of your unit (called hysteresis). For example, using a device at very high temperatures can affect its future accuracy in a lower temperature environment.
